P5SE P5SE

WISEASY P5SE
EMV Android POS

For frictionless payments at affordable upfront investment

Quad-core processor for better performance Quad-core processor for better performance

Quad-core processor for better performance

Built with cutting-edge Quad-core 2.0GHz processor and Android 13 operating system, Wiseasy P5SE ensures better operation performance for higher efficiency.

Large and ultra-responsive touch screen Large and ultra-responsive touch screen

Large and ultra-responsive touch screen

5.45'' capacitive color touch screen offers smoother operation experience.

Convenient contactless payments Convenient contactless payments

Convenient contactless payments

The antenna of P5SE is located on the front top of the device to ensure more convenient contactless payments.

Powerful high-speed printer, faster receipt printing Powerful high-speed printer, faster receipt printing

Powerful high-speed printer, faster receipt printing

Fast printing speed up to 80mm/s in virtue of professional thermal printer improves work efficiency and avoids keeping your customers waiting.

Maximize transactional continuity with powerful High-voltage Battery Maximize transactional continuity with powerful High-voltage Battery

Maximize transactional continuity with powerful High-voltage Battery

High capacity 7.2V/2600mAh battery ensures long-time operations and trouble-free payment accepting during busy hours.

Optional

Professional High-speed Scanne

Professional High-speed Scanne

Charging Cradle

Charging Cradle

Multi-port Charging Cradle

Multi-port Charging Cradle

WISEASY P5SE Specifications

Operating System

Operating System

Android 13

CPU

CPU

Quad-core 2.0GHz

Memory

Memory

LPDDR4X 2GB + eMMC 8GB

Optional: LPDDR4X 2GB + eMMC 32GB

Security Processor

Security Processor

MH2101

Display

Display

5.45 Inches (1440*720) IPSCapacitance, 2 Points touch

Network

Network

2G/3G/4G

Wi-Fi

Wi-Fi

2.4G/5G, 802.11 a/b/g/n/ac

Bluetooth

Bluetooth

Bluetooth5.1, BLE

GPS

GPS

GPS/A-GPS, Glonass, Beidou,Galileo

NFC

NFC

13.56MHz 2.Support ISO/IEC 14443 Type A&B Mifare S50/S70

Camera

Camera

Rear Camera: 2M FF Optional:5M AF Flashlight LED: Torch LED 100mA Front Camera: 2M FF (Optional)

Fingerprint

Fingerprint

Aralek A400-M (Optional)

Audio

Audio

Speaker: 0.8W Microphone: 1*MIC (Optional) Buzzer: 1*Passive (Optional)

Card Reader

Card Reader

MSR: ISO7810-7813, 3 tracks, 2 direction Rated for 300k Swipes & ESD immunity Immunity to +/- 8kV when used with metal card (no misoperation or tamper) IC Card: ISO7816/EMV,up to 300k Inserts

Card Slot

Card Slot

1*Nano SIM +2*PSAM

Optional: 1*Nano SIM + 1*Mini SIM + 1*PSAM

Optional: 1*eSIM + 1*Nano SIM+ 2*PSAM

Printer

Printer

Thermal Paper Roll Size: 58 *40mm

Motor Speed: 80mm/s

Battery

Battery

Removable, 7.2V high Voltage, 2600mAh Optional: Removable, 7.2V high Voltage, 3350mAh

Main Plug Format

Main Plug Format

Type C, USB2.0, High Speed, OTG

Rtc Coin Battery

Rtc Coin Battery

220mAh, internal, not removable

Button

Button

Power Button / Multifunction Button

Interface

Interface

Storage Expand: TF Card, MAX 128GB USB: Type C, USB2.0, High Speed, OTG (Optional:Analog headphones) Pogo Pin Expand: 6 Pogopin, VBUS/D-/D+/ID/GND/IO (Optional)

Environment

Environment

Storage temperature: -20°C to 60°C Operating temperature: -10°C to 55°C Humidity: ≤95%

Accessories

Accessories

USB Cable: TypeC, USB 2.0 - Length 1.0M

Certifications

Certifications

EMV Contact L1 / EMV Contactless L1 / EMV Contact L2 / VISA / MASTERCARD / AMEX / DISCOVER / PCI 6.x / TQM / CE / FCC / CB / IC / ROHS / WEEE
